Silicone Mobile Phone Case Making Machine From FuLund

Silicone Mobile Phone Case Making Machine From FuLund

  • Tên
    Máy lưu hóa phẳng
  • Lớp tự động
    Bán tự động, tự động, thủ công
  • Giá bán
    competitive
  • Thành phần cốt lõi
    PLC
  • Kích thước (L * W * H)
    1400 * 2000 * 1600MM
  • Vôn
    AC380V ± 5%
  • Công suất (kW)
    12
  • Từ khoá 1
    máy ép lưu hóa đế cao su
  • Từ khóa 2
    máy ép cao su lưu hóa lớn
  • Từ khóa 3
    cao su xóa báo chí lưu hóa
  • Nguồn gốc
    Trung Quốc
  • Hàng hiệu
    Fulund
  • Chứng nhận
    CE
  • Số mô hình
    FLD-B09
  • Số lượng đặt hàng tối thiểu
    1
  • Giá bán
    USD
  • chi tiết đóng gói
    TRƯỜNG HỢP GỖ
  • Thời gian giao hàng
    7 ngày
  • Điều khoản thanh toán
    T / T, Western Union, MoneyGram
  • Khả năng cung cấp
    100PCS / tháng

Silicone Mobile Phone Case Making Machine From FuLund

Silicone Mobile Phone Case Making Machine From FuLund

Fulund has a long history since its establishment in 1999. Due to the needs of development, the original brand (TYL) expanded the new brand Fulund in 2022 . Fulund has customers all over the world,such as international brands shoe manufacturer.


Fulund mainly products: Hot label machine, foam cutting machine, insole hot stamping machine, shoe tongue transfer hot stamping machine, insole heat transfer machine, insole cutting and transfer integrated machine, insole printing machine, silk screen printing machine, embossing machine, soft rubber equipment , vacuum vulcanizing machine, silicone labeling machine, glue dispensing machine, etc.

Precautions for the use of Fulund vulcanizer
Work to be aware of before use
1. Before use, it is necessary to check whether the three-phase resistance value is balanced, and check the insulation.
2. Hit the water pressure once before use to see if there is any leakage in the water pressure plate and whether the pressure test pump is working normally.
3. Check whether the heat insulation board is damaged or damp, if so, replace the heat insulation board
4. Check whether the primary and secondary wire plugs are dry. Otherwise, it is necessary to dry the plug and use the power to check whether the temperature control box instrument is normal.



1. Automatic constant temperature

2. Automatic timing

3. Automatic counting

4. Four column structure



Model 30T 40T 50(63)T
Temperature regulation At room temperature ~ 300 At room temperature ~ 300 At room temperature ~ 300
normal temperature-200 degrees heating speed about15min about15min about15min
Temperature precision automatic/±2°C automatic/±2°C automatic/±2°C
Machine operation control Circuit control Circuit PLC touch-screen
Drive way hydraulic hydraulic hydraulic
pressure 10-20Mpa 10-20Mpa 10-20Mpa
power supply AC380V ± 5%50/60Hz AC380V ± 5%50/60Hz AC380V ± 5%50/60Hz
Power: 12KW 15KW 18KW
Motor Power 4KW 4KW 5.5KW
Heating plate distance 200MM 200MM 200MM
Oil cylinder stroke 200MM 200MM 200MM
Movement mode of skateboard Automatic Automatic Automatic
Speed of rise and fall ≥15mm/s ≥15mm/s ≥25mm/s
Pressure regulation mode Pressure relay Pressure relay Digital modulation
Hot pressing time 0.1s to 999s 0.1s to 999s 0.1s to 999s
Maximum pressure 300KN 400KN 500(630)KN
Sliding plate area 440 * 500MM 440 * 500MM 460 * 550MM
Heating plate area

400 × 400MM



400 * 400MM



400 * 450MM



host volume 1400 × 2000 × 1600MM 1400 × 2000 × 1700MM 1500 × 2000 × 1800MM
weight 1200KG 1350KG

1500KG
